VS1-24 Fixed insulation cylinder indoor VCB circuit breaker

Model: VS1-24

Description

VS1-24 indoor high voltage vacuum circuit breaker applies to power system of rated voltage 24kv as a protective and control unit for power grid equipment and industrial power equipment. It can equip with KYN28(GZS1), XGN, GG-1A and other types of switchgear panels. Related products: isolated handcart, fuse handcart and voltage transformer handcart.

Outstanding Features Make You Stand Out

We play extreme caution to quality and utmost attention to detail, which makes our products so perfect.

  • administration.icon02
    Modularization of Functional Unit

    The main circuit unit and running product are coherent in interchangeability.

  • administration.icon02
    Strong Versatility

    The operating mechanism can be separated from the whole circuit breaker for convenient and easy maintenance and fix.

  • administration.icon02
    Low Maintenance

    No need of adjustment of driving unit; long-acting lubricating, reliable corrosion resistance, and high mechanical stability make low maintenance possible.

  • administration.icon02
    Long-acting Lubricating

    We apply German lubricating grease boasting lower starting torsion, stronger anti-aging and oxidation resistance.

  • administration.icon02
    Strong Corrosion Resistance

    Utilizing zinc-nickel alloy plating line with a German process to make sure our corrosion resistance is 5 to 7 times stronger than ordinary zinc-plating process.

  • administration.icon02
    Strong Expandability

    This product can easily realize diverse arrangements and combinations to meet functions like expandability and control.

  • Product Detail
  • Technical Parameters
  • Technical Drawings

VS1-24 series of indoor high voltage vacuum circuit breaker with embedded poles is three phrase A.C.50 Hz indoor power distribution equipment with the rated voltage of 24 KV. It’s used for protecting and controlling the electrical equipment in the fields of industry and mining enterprise, power plants and substation.

The main conductive circuit of this type vacuum circuit breaker with spring mechanism is embedded pole,that can greatly improve the reliability of insulation, mechanical and breaking performance and really realize the free-maintenance and longer mechanical and electrical life.This type vacuum circuit breaker conforms to national standards and the stipulations of IEC standard. The capability reaches grade of M-E2-C2.

The product is used for many kinds of switchgear like KYN28-24(GZS1) and can be fixed installation.

VS1-24 fixed type insulation cylinder indoor vcb specification

VS1-24KV, fixed type,insulation cylinder-drawing
