Medium Voltage Skid

Liyond’s medium voltage skid (MV skid) is a pre-assembled, factory-tested modular power distribution unit, combining advanced power conversion systems (PCS), a power transformer, and MV switchgear on a robust base. Designed to seamlessly convert low-voltage AC power from the PCS into medium-voltage AC power, these MV skids are widely deployed in integrated energy storage systems to ensure reliable grid integration. By integrating these core electrical assemblies into a single compact footprint, our inverter/PCS skids drastically reduce on-site installation complexity, accelerate project deployment, and deliver a cost-effective, high-efficiency power distribution solution.



Explore our product configurations below or contact our engineering team for a tailored MV skid solution.

Liyond MV Skid Solutions

Modular Design of Integrated MV Skid Solutions

To understand how our integrated MV skid solutions deliver high-efficiency power distribution and seamless grid compliance for utility scale projects, we can break down the internal architecture and modular layout:

Power Conversion Systems (PCS)

Functions as the core bi-directional conversion unit, seamlessly transforming low-voltage AC power into medium-voltage AC power.

Medium-Voltage Transformer​

Steps up the voltage output to match grid requirements, ensuring reliable performance and stable power transmission.

MV Switchgear / Ring Main Unit (RMU)​

Connected to the transformer's secondary side, it provides essential circuit protection, isolation, and medium-voltage distribution control and busbar convergence for the entire grid-tied system.

Comprehensive Protection & Safety Devices​

Equipped with a multi-layered protection system—including DC/AC input-output safeguards, surge protection devices (SPDs), insulation monitoring, and comprehensive transformer safety monitors—to ensure secure, reliable, and fault-tolerant operation in harsh utility environments.

Modular Skid Base & Integration​

Mounts all core electrical equipment onto a heavy-duty, weather-resistant skid base, creating a factory-tested, plug-and-play unit that drastically reduces on-site construction complexity and execution risks.

Why Choose Liyond's MV Skid Solutions?

Proven Engineering Expertise & Reliability

Backed by rigorous factory testing and robust industrial design, our MV skids minimize fault risks and guarantee long-term, stable operation under harsh environmental conditions.

Streamlined Project Delivery

By consolidating multi-component design, manufacturing, and testing into a pre-assembled modular unit, we significantly mitigate on-site coordination complexities and accelerate project timelines.

Lower Total Deployment Costs

By delivering a fully pre-assembled, factory-tested modular unit, we eliminate the need for complex, labor-intensive on-site assembly and heavy civil construction—drastically reducing site labor overhead, construction time, and overall project investment risks.

Comprehensive Global Support & Customization

From tailored electrical parameters and spatial configurations to responsive engineering backup, we provide end-to-end partnership to ensure seamless project execution.

FAQs of Liyond Medium Voltage Skid Solutions

Liyond MV skid integrated system products
What is a medium-voltage skid?

A medium-voltage (MV) skid, also referred to as PCS skid, is a prefabricated integrated system primarily consisting of a step-up transformer, MV switchgear, power conversion systems (PCS), and protection devices. It serves as a turnkey interface between battery energy storage systems (BESS) and MV grids.

What MV skid solutions does Liyond offer?

Liyond currently offers 5MVA and 10MVA integrated PCS skids for energy storage applications. They primarily differ in the rated capacity of the step-up transformer and the number of PCS units. Multiple PCS skids can be deployed in parallel to scale up total block capacity for utility-scale projects.

How to choose between a 5MVA and a 10MVA MV skid for your project?

A 5MVA MV skid is ideal for medium-sized BESS blocks, distributed generation, or sites with strict transport weight and footprint constraints. A 10MVA MV skid, integrating a quad-PCS architecture and multi-winding transformer, is designed for larger utility-scale projects seeking higher block-level power density and fewer grid interconnection nodes.

Can Liyond offer custom MV skids to meet specific project requirements?

Yes. Liyond offers tailored MV skid configurations engineered in accordance with applicable international standards and local grid codes. Voltage ratings, transformer vector groups, switchgear configurations, and enclosure protection levels can all be customized to match specific site conditions and project specifications.

What are the benefits of Liyond's PCS skid products?

Liyond MV PCS skids feature a highly integrated design combining protection, metering, and control function. The factory pre-assembled skid design simplifies transport and significantly reduces on-site intallation time and costs. Compliant with IEC 61850, the system seamlessly interfaces with EMS via plug-and-play communication while achieving 99% power conversion efficiency.

What are the applications of MV skids?

The MV skid is engineered to support grid-side and generation-side functions such as peak shaving, frequency regulation, black start, and renewable energy integration.
The MV skid is widely deployed in utility-scale energy storage (BESS) projects, such as centralized solar and wind power plants, large scale commercial and industrial (C&I) energy storage facilities, and data center microgrids.

What are the typical applications and deployment scenarios for this compact MV skid?

The 5MVA compact MV skid is engineered for large-scale renewable generation, utility-grade grid tie-ins, commercial and industrial (C&I) microgrids, and regional power distribution upgrades, supporting both single-unit deployment and flexible modular paralleling for multi-megawatt power projects.
